Radiation thermometer IS50-LO+ IGA50-LO+

1. • IS50-LO+・IGA50-LO + can be used for thermometry in general metallurgical heat treatment.
     Ideal for metal molds, preheating, annealing, tempering, welding, forging, hardening, sintering, melting, soldering, rolling, brazing, and laser application measurements.

1. • Suitable for measuring the temperature of samples with severe temperature changes or moving at high speed because of fast response (fastest 1msec)
     (However, since the L type is wide range, the response time is automatically extended around the lower temperature limit to reduce noise.)
   • Compatible with small spot measurement. Small samples can also be measured. 0.45 From φ /88mm.
   • A laser pilot button and temperature indicator are built into the main unit, and parameters can be set.
     Adjustment on the site has become easier.
   • Eight lenses are available in two types. The measuring area covers 88mm～4500mm.
   • A movable focusing lens (TypeII) is used to optimize the spot diameter at any position.
   • It has a built-in maximum value holding circuit, so it is also suitable for measuring moving objects.
   • The laser pilot light makes it easy to check the measurement position.
   • • Data-recording and parameter setting can be performed using the dedicated measurement software (for Windows) provided as a standard-attached product.

・DC current 0 to 20mA/4～20mA can be selected for analogue output.
・The scaling function of the minimum 50°C width enables replacement with the conventional model.
・The interface can also be switched to a RS485 with RS232 and bus-connectivity.
